ITech IT6532D User Manual

Function and Features
Copyright ©ITECH Electronics Co., Ltd. 34
Pin 6
TrigOUT
Output signal of reverse protection mode. When power
supply output is On, this pin outputs high level; when
this power supply output is Off, this pin outputs low level;
it can be used for synchronous control of On/Off for
other devices with driving capacity of 5V/5mA
Pin 18
+5V
The power supply outputs 5V voltage, which is used for
digital power supply with driving capacity of 0.1A.
Pin 19 and
Pin 20
CV_CC+
CV_CC-
The output between these two pins is used for indicating
the working status of power supply; under CV mode, the
output between these two pins is 5V; and under CC
mode, - 5V.
Pin 21
Voltage
Program
( Voltage
setting)
Output voltage of analog control:
In setting the Voltage and 10v, the input analog range
should be 0-10V voltage,
and the regulated output
voltage should be from 0 to full range;
In setting the Voltage and 5v, the
input analog range
should be 0-5V voltage,
and the regulated output
voltage should be from 0 to full range;
In setting the Resistance and 10K,
the input analog
range should be 0-10K resistance, and the regulated
output voltage should be from 0 to full range;
In setting the Resistance and 5K,
the input analog
range should be 0-5K resistance,
and the regulated
output voltage should be from 0 to full range;
Pin 22
REF_10V
The 10V reference voltage output by the power supply
can be connected to a resis
tance subdivision for analog
control.
Pin 23
Current
Program
( Current
Setting)
Output current of analog control:
In setting the Voltage and 10v,
the input analog range
should be 0-10V voltage,
and the regulated output
current should be from 0 to full range;
In setting the Voltage and 5v,
the input analog range
should be 0-5V voltage, and the regulated output current
should be from 0 to full range;
In setting the Resistance and 10K,
the input analog
range should be 0-10K resistance, and the regulated
output current should be from 0 to full range;
In setting the Resistance and 5K,
the input analog
range should be 0-5K resistance,
and the regulated
output current should be from 0 to full range;
Pin 24
Voltage
Monitor
( Voltage
monitoring)
The actual value from monitoring is the corresponding
monitor voltage value. For example,
when the analog
voltage is 10V, power supply control voltage 0~80V and
the power supply output voltage 20V, this pin will output
2.5V voltage. Similarly, when the analog voltage is 5V,
control voltage 0~80V and the power supply output
voltage 20V, this pin will output 1.25V voltage.
Pin 25
Current
Monitor
( Current
monitoring)
The actual value from monitoring is the corresponding
monitor voltage value. For example, when th
e analog
voltage is 10V, power supply control current 0~120A
and the power supply output current 12A, this pin will
output 1V voltage. Similarly, when the analog voltage
is 5V, control current 0~120A and the power supply
output voltage 12A, this pin will output 0.5V voltage.
Pins 9, 10,
11, 12 and
13
Connection
to AGND
Ground wires for analog interfaces ( including Pin 21
VPRG, Pin 22 REF_10V, Pin 23 IPRG, Pin 24 VMON,
Pin 25 IMON).
Pins 4, 5, 7,8
Internal
connection
to DGND
Ground wires for Pin 15 EXT ON, Pin 3 SHUT OFF, Pin
16 POWER OK, Pin 17 TrigIN, Pin 6 TrigOUT,Pin 19
CV_CC+ and Pin 20 CV_CC-.
