ITech IT6821 - Calibration Order; Output Order; Output Measure Order; Chapter 3 SCPI Condition Register

6
2.3 Calibration Order
CALibration
:SECure
[:STATe] {<ON|OFF>,<quoted code>}
]:STATe]?
:VOLTage
:LEVel {<level> }
[:DATA] {<numeric value>}
:CURRent
:LEVel {<level> }
[:DATA] {<numeric value>}
:SAVe
:INITital
2.4 Output Order
OUTPut
[:STATe] <b>
[:STATe]?
[SOURce:]
VOLTage
[:LEVel][:IMMediate][:AMPLitude]
[:AMPLitude]?
:PROTection[:LEVel]
[:LEVel]?
CURRent
[:LEVel][:IMMediate][:AMPLitude]
[:AMPLitude]?
2.5 Output Measure Order
MEASure
[:SCALar]
:VOLTage[:DC]?
:CURRent[:DC]?
:POWer[:DC]?
Chapter 3 SCPI Condition Register
You can get the condition of power supply and read parameter from the operation register. The
power supply can get the different state by 4 condition registers. These registers are status byte
register, standard event register, quest condition register and operation status register. The status
byte register stores the information of 3 other register. You can get each register’s meaning from
the following table:
BIT Signal Meaning
0 CV
operation status register.
The power supply is in constant voltage condition.
