15
6
th
byte
The higher byte of current value.
7
th
byte
The highest byte of current value.
From 8
th
To 25
th
byte
System reserve
27
th
byte
Sum code
Represent current by 4 bytes of Hex. Lower bytes are in the front location, higher bytes are in
the later location. For example: current is 3.0000A，Hex code is 0X00007530，NO. 4 bye is
0X30，NO. 5 bye is 0X75，NO. 6 bye is 0X00，NO. 7 bye is 0X00。
8. Set / Read voltage value of CV mode.（2CH/2DH）
1
st
byte
Start bit ( AAH )
2
nd
byte
Address (0—31,0XFF)
3
rd
byte
Command（2CH/2DH）
4
th
byte
The lowest byte of voltage value.
5
th
byte
The lower byte of voltage value.
6
th
byte
The higher byte of voltage value.
7
th
byte
The highest byte of voltage value.
From 8
th
to 25
th
byte
System reserve
26
th
byte
Sum code
Represent voltage by 4 bytes of Hex. Lower bytes are in the front location, higher bytes are in
the later location. For example :voltage is 16.000V，Hex code is 0X00003EB0，4th byte 0XB0，
5TH byte is 0X3E，6th byte is 0X00，7th bytes 0X00。
9. Set / Read watt value of CW mode（2EH/2FH）
1
st
byte
Start bit ( AAH )
2
nd
byte
Address (0—31,0XFF)
3
rd
byte
Command（2EH/2FH）
4
th
byte
The lowest byte of max power value
5
th
byte
The lower byte of max power value
6
th
byte
The higher byte of max power value
7
th
byte
The highest byte of max power value
8
th
to 25
th
byte
System reserve
26
th
byte
Sum code
