ITech IT8702 User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 66
Dynamic
mode
CC mode
T1＆T2
20uS~3600S /Res:1u S
Accuracy
5uS+100ppm
Rising/falling
slope
*4
0.0001~0.1A/uS
0.001~0.8A/uS
Min Rising time
*5
≒20uS
≒20uS
Measuring range
Readback
voltage
Range
0~18V
0~500V
Resolution
1 mV
10 mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback
current
Range
0~3A
0~20A
Resolution
0.01mA
0.1mA
Accuracy
±(0.05%+0.05%FS)
Readback
power
Range
300W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
OPP
≒310W
OCP
≒3.3A
≒22A
OVP
≒530V
OTP
≒85℃
Specification
Short-circuit
Current（CC）
≒3.3/3A
≒22/20A
Voltage（CV）
0V
Resistance（CR）
≒240mΩ
Input impedance
≒1MΩ
dimension
82*183*573mm
weight
5KG
safety
CE
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is:
（ 1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08) ）
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current
*5 Minimum rise time: 10%-90% current rise time
Model
IT8733B
Rated value
( 0～40 ℃)
Input voltage
0~500V
Input current
0~30A
Input power
500 W
Min operation
voltage
0.54V/3A
5.4V/30A
CV mode
Range
0~18V
0~500V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.025%FS)
±(0.05%+0.025%FS)
CC mode
Range
0~3A
0~30A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CR mode
*1
Range
0.2Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *2
0.01%+0.0008S
CP mode
Range
500W

ITech IT8702 Specifications

General

Brand	ITech
Model	IT8702
Category	Test Equipment
Language	English
