ITech IT8702 User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 67
*3
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Dynamic mode
Dynamic mode
CC mode
T1＆T2
20uS~3600S/Res:1uS
Accuracy
5uS+100ppm
Rising/falling
slope
*4
0.0001~0.08A/uS
0.001~0.8A/uS
Min Rising time
*5
≒25uS
≒25uS
Measuring range
Readback voltage
Range
0~18V
0~500V
Resolution
1 mV
10mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback current
Range
0~3A
0~30A
Resolution
0.01mA
0.1mA
Accuracy
±(0.05%+0.05%FS)
Readback power
Range
500W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
OPP
≒510W
OCP
≒3.3A
≒33A
OVP
≒530V
OTP
≒85℃
Specification
Short-circuit
Current（CC）
≒3.3/3A
≒33/30A
Voltage（CV）
0V
Resistance
（CR）
180mΩ
Input impedance
1MΩ
dimension
82*183*573mm
weight
5KG
safety
CE
*1 The voltage/current input is no less than 10% FS
*2 The scope of read-back resistance is:
（ 1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08) ）
*3 The voltage/current input is no less than 10% FS
*4 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current
*5 Minimum rise time: 10%-90% current rise time
Model
IT8722P
Rated value
( 0～40 ℃)
Input voltage
0~80V
Input current
0~20A
Input power
250W *1
Min operation voltage
0.15V/3A
1.0V/20A
CV mode
Range
0~18V
0~80V
Resolution
1Mv
10mV
Accuracy
±(0.05%+0.025%FS)
±(0.05%+0.025%FS)
CC mode
Range
0~3A
0~20A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CR mode
Range
0.05Ω~10Ω
10Ω~7.5KΩ
