ITech IT8702 User Manual

Specifications
Copyright © Itech Electronic Co., Ltd. 68
*2
Resolution
16bit
Accuracy
0.01%+0.08S *3
0.01%+0.0008S
CP mode
*5
Range
250W *4
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Dynamic mode
Dynamic mode
CC mode
T1＆T2
20uS~3600S/Res:1uS
Accuracy
5uS±100ppm
Rising/falling slope
*6
0.0001~0.2A/uS
0.001~1.6A/uS
Min Rising time
*7
≒10uS
≒10uS
Measuring range
Readback voltage
Range
0~18V
0~80V
Resolution
0.1 mV
1 mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback current
Range
0~3A
0~20A
Resolution
0. 01mA
0.1mA
Accuracy
±(0.05%+0.05%FS)
Readback power
Range
250W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
OPP
≒250W
OCP
≒3.3A
≒22A
OVP
≒82V
OTP
≒85℃
Specification
Short-circuit
Current（CC）
≒3.3/3A
≒22/20A
Voltage（CV）
0V
Resistance（CR）
≒50mΩ
Input impedance
300KΩ
dimension
82*183*573
weight
5KG
*1 Dynamically allocate power. The maximum power of single channel is 250W. The total power
of both channels is less than or equal to 300W. The average power of each channel is 150W.
*2 The voltage/current input is no less than 10% FS (FS= Full Scale)
*3 The scope of read-back resistance is ( 1/(1/R+(1/R)*0.01%+0.08),1/(1/R-(1/R)*0.01%-0.08) )
*4 Dynamically allocate power. The maximum power of single channel is 250W. The total power
of both channels is less than or equal to 300W.
*5 The voltage/current input is no less than 10% FS
*6 Ascending/descending slope: 10%-90% current ascending slope from 0 to maximum current
*7 Minimum rise time: 10%-90% current rise time
Model
IT8723P
Rated value
( 0～40 ℃)
Input voltage
0~80V
Input current
0~45A
Input power
300W
Min operation
voltage
0.14V/4.5A
1.4V/45A
CV mode
Range
0~18V
0~80V
