Specifications
Copyright © Itech Electronic Co., Ltd. 59
Chapter5 Specifications
5.1 Main technical parameters
IT8722 is double channels module which dynamically allocates power and the
specification of each channel is the same.
Model
IT8722
Rated value
( 0～40 ℃)
Input voltage
0~80V
Input current
0~20A
Input power
250W *1
Min operation
voltage
0.15V/3A
1.0V/20A
CV mode
Range
0~18V
0~80V
Resolution
1mV
10mV
Accuracy
±(0.05%+0.025%FS)
±(0.05%+0.025%FS)
CC mode
Range
0~3A
0~20A
Resolution
0.1mA
1mA
Accuracy
±(0.05%+0.05%FS)
±(0.05%+0.05%FS)
CR mode
*2
Range
0.05Ω~10Ω
10Ω~7.5KΩ
Resolution
16bit
Accuracy
0.01%+0.08S *3
0.01%+0.0008S
CW mode
*5
Range
250W *4
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Dynamic mode
Dynamic mode
CC Mode
T1＆T2
20uS~3600S/Res:1uS
Accuracy
5uS±100ppm
Rising/falling
slope *6
0.0001~0.2A/uS
0.001~1.6A/uS
Min Rising time
*7
≒10uS
≒10uS
Measuring range
Readback voltage
Range
0~18V
0~80V
Resolution
0.1 mV
1 mV
Accuracy
±(0.025%+0.025%FS)
±(0.025%+0.025%FS)
Readback current
Range
0~3A
0~20A
Resolution
0. 01mA
0.1mA
Accuracy
±(0.05%+0.05%FS)
Readback power
Range
250W
Resolution
10mW
Accuracy
±(0.2%+0.2%FS)
Protection range
OPP
≒250W
OCP
≒3.3A
≒22A
OVP
≒82V
OTP
≒85℃
Specification
Short-circuit
Current（CC）
≒3.3/3A
≒22/20A
Voltage（CV）
0V
Resistance
（CR）
≒50mΩ
