PREPARATION PROCEDURE
1. Ensure all valves are closed.
2. Make sure the car’s A/C system is of R134a kind.
3. Clean the car’s connectors.
4. Connect tubes to the car’s A/C system in this way:
RED high pressure, BLUE low pressure
5. Connect power cable to power network (220-240 V) and turn
on the station. The refrigerant fluid quantity contained in gas
tank will appear on display (for example: 3550 grams),
otherwise the display will indicate “LOW GAS” if gas quantity is
lesser than 2000 grams (Note: this is just a warning message,
but the charge can be executed anyway).
6. If the gas is not enough, refill the gas tank within 80% of its
capacity, in this way:
Press DOWN twice, commuting display to TANK mode.
Confirm by pressing OK.
Connect the external gas tank to the station using the
high pressure coupling (RED), orienting the tank as in
Figure 4 according to float presence or absence.
