Nominal Voltage: 12.8v
C20 Rating usable amps 10v: 100Ah
Short Circuit Protection: Yes
Optimum Temperature Range: +5 to +60°C
BMS Operational Temperature Range: -40 to 80°C
Safety Protection Isolator: 80°C
Recommended Charge Current: 10 - 50A
Maximum Charge Current: 100A (5sec)
Recommended Charge Voltage: 14.2 -14.6v
BMS Charge Cut Off Voltage: 15.6v
BMS Low Voltage Cut Off: 8v
Continuous Discharge: 100A (175A 5 mins)
Peak Discharge: 250A 5 sec
Life Cycles 65%: 5000
Life Cycles 55%: 8000 +
UL certified 1642
CE Certified
Rohs Certified
UN38.3 Certified
ISO 9001 Certified
ISO 1400 Certified
Dimensions (LxWxH): 394*110*286mm
Weight approx: 11.7kg
Terminal Type: M8
Case Material: ABS
