ATTACHING CONDUIT ADAPTERS
Page 24
Using the 2”- 4” Adapters (51 mm. - 102 mm.)
Place the desired conduit adapter size into the top of the universal adapter.
Slide the adapters toward the puller until the adapter is all the way back. (Fig. 4)
FIG. 4
FIG. 5
Tighten the 1/2” (12.7 mm.) bolt on the side of the head body. (Fig. 5) Remove the adjustment hitch
pin to slide the puller into position and place the conduit adapter into the conduit (Fig. 6).
Replace all hitch pins before pulling.
FIG. 6
