ATTACHING CONDUIT ADAPTERS
Page 23
Using the Universal Adapter
Loosen the 1/2” (12.7 mm.) bolt (Fig.1) on either side of the front head. Slide the universal adapter
in or out (Fig. 2) to accommodate the appropriate size of conduit. Make sure that the adapter
engages the conduit. (Fig. 3)
Note: The universal adapter is to be used for pulling loads under 5,000 lbs./2,268 kg.
For loads over 5,000 lbs./2,268 kg., the conduit adapters provided with your puller should
always be utilized.
FIG. 1
FIG. 2
FIG. 3
