28
Section 5 Model 763A Gage Pressure Transmitter
!
WARNING: Except for replacing O-rings, fasteners, and connector as-
semblies, no
repair or component replacement on the Model 763A
is authorized. Unauthorized repairs void any
to
reports for design basis event performance.
Table 5.1—Model 763A Replacement Parts
Item Description Part No. Per Unit
1
Screw, Rd. Hd., S.S., 10-32 x 5/16
9A-C0111-0048J 4
2
Washer, Lock, S.S., #10
9A-C0003-0032K 4
3
Bracket
9A-C0763-1016C 1
4*
O-ring (Case)
9A-C0001-1057R 1
5*
O-ring (Cover)
9A-C0001-1056R 1
6*
Washer, Flat, S.S., 1/4
9A-C0003-1029K 8
7*
Screw, Cap, Socket Hd., S.S., 1/2-20 x 1/2
9A-C0220-1009J 8
8
Case Cover (Optional)
9A-C0764-1066C 1
9
Case Cover (Standard, External Adjustment)
9A-C0764-1262B 1
10*
O-ring (External Adjustment)
9A-C0001-1050R 2
11
Plug, External Adjustment Calibration
9A-C0764-1247C 2
12
Connector Assembly, EGS QDC
9A-C0764-1304B 1
13* O-ring, QDC (Not Shown)
9A-C0001-1218R 1
14
Tool, Barton Style Connector Assembly Installation
(Not Shown)
9A-0764-1174B 1
16*
Lubricant, O-Ring, Dow Corning High Vacuum
Grease
(Not Shown)
9A-C0002-1003U A/R
17 EGS QDC Thread Lubricant (Not Shown)
9A-C0002-1067U A/R
* Recommended Spare Part
