1. WATER AND DRAINAGE
Water quality has a remarkable influence on the appearance, hardness
and flavor of the ice as well as, on the machines condensated by water,
on the life of the condenser.
2. CONNECTIONS TO THE WATER NETWORK
Use a flexible pipe (1.3 m – 4.27 feet length) with the two filter joints
supplied with the machine. Arrange the necessary appliances according
to regulations or current norms to prevent water return to the network.
Pressure should be established between 0.1 MPa and 0.6 MPa (1-6
BAR). If pressures overpass such values, install the necessary
corrective devices.
3. CONNECTION TO DRAINAGE
Drainage should be located lower to the machine level, at 150 mm (5.91 inches) minimum.
It is convenient that the drainage pipe is of 30 mm (1.18 in) of interior diameter and with a
minimum gradient of 3 cm (1.18 in) per meter (see figure).
THREAD THE SUPPORT LEGS TO THE BASE OF THE MACHINE ON THE
HOUSING SET TO SUCH END AND REGULATE THE HEIGHT AS TO HAVE
THE EQUIPMENT PERFECTLY LEVELED.
In R290 units under the counter, the passage of
air can be in front. The unit can work recessed
with a loss of production.
