ITW Mima Girotec RDL - Page 2

RDL PL/PLB ST/STB WT2 WT3/ST3
Height 2100mm 2420mm 2400mm 2405mm 2405mm
Length 1790mm 1780mm 1700/1860mm 1700mm 1870mm
Width 720mm 665mm 1330/1590mm 1330mm 1365mm
Machine weight 210kg 180kg/195kg 160kg/315kg 150kg 170kg/180kg
Max. weight of film roll 3kg 3kg 3kg 3kg 3kg
Max. pallet dimensions in RDL 1000*1200*1850mm / max. 1000kg
PL/PLB 1000*1200*2050mm / max. 1000kg
ST/STB 1000*1200*1850/2050mm
WT2 1000*1200*2000mm
WT3/ST3 1200*1200*2000mm
Rotation Area (RA) RDL 2055mm
PL 2055mm
ST 2055mm
WT2 2055mm
WT3/ST3 2335mm
Electrical supply ST, WT2 and ST3, WT3 220-240v/50Hz
RDL ,STB,PLB and PL power supply 24v, battery charger 220-240v/50Hz
TECHNICAL SPECIFICATIONS
SEMI-AUTOMATIC MACHINES
V3.1
RDL
PL ST(B) WT
