MACHINE MAIN COMPONENTS
1
RDL:
1. Boom
2. Rotary arm
3. Film distributor
4. Film roll
5. Battery box
6. Connection for
battery charger
7. Lock for
rotating arm
8. Operating panel
9. Tower
WT:
1. Boom
2. Rotary arm
3. Film distributor
4. Film roll
5. Bottom frame
6. Mains cable
7. Operating panel
8. Tower
9. Wall bracket
10. Power supply unit
cover
11. Floor stand
ST/STB:
1. Boom
2. Rotary arm
3. Film distributor
4. Film roll
5. Bottom frame
6. Mains cable
7. Operating panel
8. Tower
9. Tensioner
10.Power box (STB )
11. Stabilizer
PL:
1.Boom
2. Rotary arm
3. Film distributor
4. Film roll
5. Pallet stop
6. Mains cable
7. Operating panel
8. Tower
