ITW Mima Girotec RDL - Operation; Performing the Wrapping

4
2.6 Wrapping
ST/STB and WT:
1. Move the packaged
goods with a low lift
platform truck or fork
lift truck to the pallet
end stop, so that the
wrapping arm does
not touch the pallet
during the wrapping
process.
2. Pull the film out far
enough to enable it to
be fastened to the
corner of the pallet.
Tie the film firmly to
the pallet.
3. Press the Start
button
RDL and PL/PLB:
1. Move the catch
downwards to
horizontal position.
(RDL)
2. Move the system
under the pallet with
the packaged goods
3. Pull the film out
far enough to enable
it to be fastened to
the corner of the
pallet. Tie the film
firmly to the pallet.
4. Press the Start
button
OPERATION
SEMI-AUTOMATIC MACHINES
