12KHR-N
1 – 1
12KHR-N
5GTXKEG/CPWCN
CHAPTER 1. SPECIFICATION
[1] SPECIFICATION
1. 12KHR-N
NOTE: The conditions of star”✩” marked item are based on ‘EN14511’.
MODEL INDOOR UNIT OUTDOOR UNIT
ITEMS 12KHR-N
Rated cooling capacity (Min– Max.) kW 3.5 (0.9 - 4.0)
Rated heating capacity (Min–Max.) kW 4.6 (0.9 - 6.5)
Moisture removal (at cooling) Liters/h 1.2
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage V 220-240
Rated current ڏ
(Min - Max.)
Cool A 4.2 (0.9 - 5.7 )
Heat A 5.0( 0.9 - 7.4 )
Rated input ڏ
(Min - Max.)
Cool W 920 (200- 1250)
Heat W 1075 (160 - 1700)
Power factor ڏ
Cool % 95
Heat % 92
Maximum operating current A 9.6
Compressor Type Hermetically sealed rotary type
Model DA111A1F22F
Oil charge 450cc (Ester oil VG74)
Refrigerant system Evaporator Louver Fin and Grooved tube type
Condenser Corrugate Fin and Grooved tube type
Control Expansion valve
Refrigerant (R410A) 1180g
De-lce system Micro computer controled reversed systems
Noise level
(at cooling)
High dB(A) 40 47
Low dB(A) – –
Soft dB(A) 27 –
Fan system
Drive Direct drive
Air flow quantity
(at cooling)
High m3/min. 9.3 32.2
Low m3/min. 7.6 –
Soft m3/min. 5.2 –
Fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4"
Drain piping mm O.D I16
Others
Safety device Compressor: Thermal protector
Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 790 780
Height mm 260 540
Depth mm 290 265
Net weight kg 11 36
To Next Page
