IVT AY-XP12FR-N Service Manual

AYXP12FRN
1 – 1
AYXP12FRN
Service Manual
CHAPTER 1. SPECIFICATION
[1] SPECIFICATION
1. AY-XP12FR-N – AE-X12FR-N
NOTE: The condition of star”✩” marked item are ‘ISO5151’ : 1994(E), contition T1.
MODEL INDOOR UNIT OUTDOOR UNIT
ITEMS AY-XP12FR-N AE-X12FR-N
Cooling capacity(Min. > Max.) kW 3.5 (0.9 - 4.0)
Heating capacity(Min. > Max.) kW 4.2 (0.9 - 6.0)
Moisture removal(at cooling) Liters/h 1.1
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage V 230
Rated current ✩
(Min - Max.)
Cool A 4.3 (0.8 - 6.0)
Heat A 4.5 (0.7 - 7.5)
Rated input ✩
(Min - Max.)
Cool W 900 (150 - 1300)
Heat W 970 (130 - 1700)
Power factor ✩ Cool % 91
Heat % 94
Compressor Type Hermetically sealed rotary type
Model 5RS092XDF
Oil charge 320cc (RB68A or Freil Alphc 68M)
Refrigerant system Evaporator Louver Fin and Grooved tube type
Condenser Corrugate Fin and Grooved tube type
Control Expansion valve
Refrigerant (R410A) 1000g
De-lce system Micro computer controled reversed systems
Noise level
(at cooling)
High dB(A) 43 49
Low dB(A) 39 –
Soft dB(A) 27 –
Fan system
Drive Direct drive
Air flow quantity
(at cooling)
High m3/min. 10.7 30.2
Low m3/min. 9.3 –
Soft m3/min. 6.0 –
Fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 1/2", 1/4"
Drain piping mm O.D φ18
Others
Safety device Compressor: Thermal protector
Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 790 780
Height mm 278 540
Depth mm 198 265
Net weight kg 10 37
