IVT Greenline D14 - Dimensions and Connections

31
Dimensions and connections (models DE14-16)
(1) Return radiator
(2) Riser radiator
(3) Return electric water
heater (only E)
(4) Riser electric water
heater (only E)
(5) Heat transfer fluid out
(6) Heat transfer fluid in
(7) Electrical connections
(7)
Front
®®
®
®
®
(1)
(2)
(3)
(4)
(6)
(5)
248 385 513
596
571
495
317
121
1500 mm
(1525 mm incl. feet)
®®
®
380
®
