42
Safety valve
Expansion tank
Filling and venting valve
*Manual venting valve
*If the expansion vessel can
not be placed at the highest
point, then manual venting is
recommended.
Particle
filter
IVT Greenline
3
1
The table shows the mixture in volume litre/ metre
Hose type
Anti-
freeze type
Ethanol
Propylene glycol
Litres of water
0.71
0.65
Litres of antifreeze
40/35
0.29
0.35
Litres of water
0.42
0.39
Litres of antifreeze
0.18
0.21
32/28
The table shows the mixture in weight percent
Ethanol
Propylene glycol
25%
35%
Example: 200 metres of hose type 40/35 with Brinol gives 200 x 0.29 litres Brinol/ meter = 58 litres
Brinol and 200 x 0.71 litres water/ metres = 142 litres water.
Hose type
40/35
32/28
