— IWATA ECLIPSE SERIES AIRBRUSHES • MASTER PARTS LIST —
PRICE ITEM HP HP HP HP ALSO
# ITEM DESCRIPTION CODE # BCS BS CS SBS FITS
1 Needle Cap A I 601 1 n n n n
2 Nozzle Cap 0.50 mm B I 602 1 n x x x
0.35 mm C I 602 2 x n n n
3 Head Cap C I 603 1 n n n n
4 Nozzle 0.50 mm C I 604 1 n opt opt opt
0.35 mm E I 604 2 opt n n n
5 Packing Head O-Ring A I 605 1 n n n n
6 Body* N/A n x x x
N/A x x n x
N/A x n x x
N/A x x x n
7 Packing-Valve Piston O-Ring B I 580 1 n n n n ICM-B
8 Air Valve Guide Body B I 608 1 n n n n
9 Air Valve A I 609 1 n n n n
10 Air Valve Spring A I 510 4 x n n n ICM-B
11 Air Valve Guide Screw A I 611 1 n n n n
12 Main Lever (Trigger) C I 612 1 n n n n
13 Needle Chucking Set (PTFE) A I 725 1 n n n n HP-BC, BC2
14 Needle Chucking Guide C I 715 1 n n n n
15 Needle Spring A I 135 2 n x x x HP-A
A I 135 1 x n n n
16 Spring Guide C I 170 2 n n n n HP-C
17 Needle 0.50 mm B I 617 1 n opt opt opt
0.35 mm B I 617 2 opt n n n
18 Needle Chucking Nut A I 120 2 n n n n HP-C
PRICE ITEM HP HP HP HP ALSO
# ITEM DESCRIPTION CODE # BCS BS CS SBS FITS
19 Single Cut Handle E I 619 1 n n n n
Pre-Set Handle G I 155 2 opt opt opt opt HP-C
Crown Cap G I 105 0 opt opt opt opt HP-C
Bottles 2 oz I 480 2 n x x x BC/BC2
(See Price List for Other Sizes)
21 Lid
Eclipse CS C I 618 1 x x n x
Side Cup 1/4 oz C I 095 7 x x x opt HP-SB
Gravity Cup 1/3 oz C I 095 8 x x opt opt HP-SB
Gravity Cup 1/2 oz C I 095 8 x x x opt HP-SB
22 Fluid Cup
Side Cup 1/8 oz G I 070 3 x x x n HP-SB
Side Cup w/Lid 1/4 oz G I 070 4 x x x opt HP-SB
Gravity Cup w/Lid 1/2 oz G I 070 6 x x x opt HP-SB
22a Lower Lid 1/8, 1/4 oz B I 095 6 x x x n HP-SB
22b Packing Lower Lid A I 150 5 x x x n HP-SB
23 Blanking Cover A I 045 2 x x x n HP-SB
Quick Fit Set I 160 3 opt opt opt opt
(Quick Disconnect that Screws
Onto the Air Hose and an
Adaptor that Screws Onto
the Airbrush)
Quick Fit Adaptor I 160 4 opt opt opt opt
(Adaptor that Screws
onto the Airbrush)
n = yes x = no opt = optional
