NM
MPL, MPP)
T, A
EGT, CHT
1340
1430
376
385
EGT, left, CHT, right. Dot
indicates cylinder
T, A
TIT, Turbine Inlet
Temperature
1370
1450
TIT
T, A
Oil Temperature
177
180
OIL
T, A
TIT #2 Second
Turbine Inlet
Temperature
1450
1460
T 12
Only one of these three options
may be installed in the aircraft
T, A
Carburetor
Temperature
20
25
CRB
T, A
Shock Cooling
-30
-40
CLD
Dot indicates fastest cooling
cylinder
Section 9 - Long Term Memory
The EDM-760/790 Long Term Memory will record and store all
displayed measurements once every six seconds (or at the programmed
interval of between 2 and 500 seconds). At a later time, transfer them to a
USB Thumb Drive as an intermediate courier, or laptop PC.
When you retrieve recorded data to your laptop PC you can choose to
retrieve all the data in stored in the EDM-760/790, or only the new data
recorded since your last retrieval. In either case, no data in the EDM-
760/790 is erased. The data will be saved in the PC in a file in a
compressed format.
The amount of total data that the EDM-760/790 can store will vary
depending on how rapidly the measured temperatures change. The typical
storage is 10-15 hours for both engines, but may vary depending on which
options are installed. When the memory becomes full, the oldest data will
be discarded to make room for the newest. You may place a mark at the
For Your Safe Flight Page 35
