Format Baud rate
NMEA-183
(Marine
Navigation Data
Format)
4,800 This is the format for most handheld
GPS receivers. Loran must have
sentences RMA & RMB. GPS must
have sentences RMB & RMC.
Aviation Data
Format
9,600 “Output sentence type 1” Req’d
sentences: A, B, C, D, E, I and L first
char id byte. Sentence terminator
either <CR><LF> or <CR>.
Northstar
(Northstar binary)
1,200 M1 setup select “NO EXTENDED”,
“NAV ONLY”
Setting GPS-C Fuel Flow Communications Format
GPS-C
Input to GPS; output of EDM-760
0 No fuel data output
1 Garmin (Shadin Miniflow format)
2 Allied Signal (format B)
3 Arnav/EI fuel data
4 Allied Signal (format C) *
5
(not assigned)
6 UPS/Garmin fuel/air data
Diagnostic Messages, Fuel Flow
The following displays indicate a malfunction in the Fuel Flow
Option transducer or associated electrical connections:
0.0
GPH
Zero’s indicate Fuel flow is too low to register
---
GPH
Dashes indicate No fuel flow transducer signals
---
H.M
Dashes indicate No fuel flow transducer signals
Page 52 Engine Data Management
