Parts List
Bag No. Description Qty.
1 Upper wing panel 1
2 Lower wing panel with servo holes 1
3 Fuselage 1
Wood wing dowels 4
Servo tray for throttle and elevator 1
Rubber strips for wing seating 1
4 Horizontal tailplane & elevator 1
5 Vertical fin and rudder 1
6 Wing tip struts 2
7 Engine mount (L & R) 2
M4 x 20 bolt (to fix engine mount on firewall) 4
M4 blind nuts 4
M4 x 25 bolt (to fix engine on the mount) 4
M4 self-lock nut 4
Washer for M4 screw 4
8 Fuel tank 1
9 Main landing gear 1
10 Main wheels 2
Wheel collars 4
Landing gear saddle clamps 4
Saddle clamp screws (M3 x 8) 8
11 Hard wood elevator push-rod with steel wire and metal clevis 1 set
Elevator horn 1
Horn fixing screws (M2 x 12) 2
M2 nuts 4
12 Rudder pull-pull cable system 1 set
Rudder horn 2
M12 x 12 screws 2
M2 nuts 2
13 Aileron push-rod with clevis 2 set
Aileron horn 2
Horn fixing screws (M2 x 12) 4
M2 nuts 4
14 Throttle control cable 1
Aileron ball linkage and ball caps 2
Tail skid 1
