PARTS LIST
Model Model Model Model Model
Key Description 777-0001 777-0003 777-9001 7777-9003 7777-9051
1 Shaft 6718-0000 6718-0000 6718-0000 6718-0000 6718-0000
2 Retaining Ring (Brg. to Shaft) 18713-0000 18713-0000 18713-0000 18713-0000 18713-0000
3 Ball Bearing 92600-0060 92600-0060 92600-0060 92600-0060 92600-0060
4Retaining Ring (Brg. to Body) 18724-0000 18724-0000 18724-0000 18724-0000 18724-0000
5Key 9215-0000 9215-0000 9215-0000 9215-0000 9215-0000
6 Cam (Brass) 934-0000 934-0000 934-0000 934-0000 2431-0000
7Wearplate 4156-0000 4156-0000 4156-0000 4156-0000 4156-0000
8 Seal Spacer
†
3166-0000 3166-0000 — — —
9 Seal (Lip)* ** 92700-0060 92700-0060 — — —
10 O-Ring*
†
92000-0210 92000-0210 — — —
11 Seal (Face)* ** — — 96080-0080 96080-0080 96080-0080
12 Screw (Cam) 91004-0090 91004-0090 91004-0090 91004-0090 91004-0090
13 Slinger, used with Lip Seal only 3181-0000 3181-0000 3181-0000 3181-0000 3181-0000
14 Body 798-0020 798-0020 798-0020 798-0020 798-0020
15 Screw (End Cover) 91003-0010 91003-0010 91003-0010 91003-0010 91003-0010
16 End Cover 11831-0000 11831-0000 11831-0000 11831-0000 11831-0000
17 Gasket* 890-0000 890-0000 890-0000 890-0000 2432-0000
18 Impeller* - Neoprene, Brass Insert 17937-0001 — 17937-0001 — 17937-0001
Nitrile, Brass Insert — 920-0003 — 920-0003 —
Service Kit (Not Shown) 90010-0001 90010-0003 90118-0001 90118-0003 90118-0001
* Parts supplied in Service Kit.
† Used for models prior to August 1, 1964.
NOTE: 5915-0001, High Pressure Neoprene Impeller available; contact factory for application recommendations.
** When replacing shaft seal, the outer bearing seal is often distorted beyond serviceability and should be replaced.
