DIMENSIONAL DRAWING
Inches (Millimeters)
PERFORMANCE TABLES
Model 777-9001
Total Head 500 RPM 1160 RPM 1750 RPM 2100 RPM 2750 RPM 3000 RPM
psi Feet of Water GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP
(kg/sq cm) (Meters) (L/Min) (L/Min) (L/Min) (L/Min) (L/Min) (L/Min)
4.3 10 6.0
1/4
14.7
1/3
23.3
3/4
27.9
3/4
33.8
1-1/2
35
1-1/2
(0.3) (3.0) (22.7) (55.6) (88.2) (105.6) (127.8) (132.5)
8.7 20 5.6
1/4
13.8
1/2
22.0
3/4
26.8
1-1/2
32.9
1-1/2
34.3
1-1/2
(0.6) (6.1) (21.2) (51.9) (8.3) (101.3) (124.5) (129.8)
17.3 40 4.6
1/4
11.5
1/2
19.3
3/4
23.9
1-1/2
30.5
1-1/2
32.5
1-1/2
(1.2) (12.2) (17.4) (43.5) (73.1) (90.5) (115.5) (123.0)
26.0 60 — — 7.8
3/4
15.5
1
19.2
1-1/2
26.1
2
29.3
2
(1.8) (18.3) (29.5) (58.7) (72.5) (98.6) (110.9)
34.6 80 — — — — 10.0
1
13.2
1-1/2
19.9
2
23.5
2
(2.4) (24.4) (37.9) (49.8) (75.3) (89.1)
Model 777-9051
Total Head 500 RPM 1160 RPM 1750 RPM 2100 RPM 2750 3000 RPM
psi Feet of Water GPM HP GPM HP GPM HP GPM HP GPM HP GPM HP
(kg/sq cm) (Meters) (L/Min) (L/Min) (L/Min) (L/Min) (L/Min) (L/Min)
4.3 10 4.0
1/4
8.7
1/4
13.6
1/2
16.7
3/4
22.3
1
34.0
1
(0.3) (3.0) (15.1) (32.9) (51.5) (63.2) (84.4) (90.8)
8.7 20 3.4
1/4
8.0
1/3
12.8
1/2
15.8
3/4
21.2
1
23.2
1-1/2
(0.6) (6.1) (12.9) (30.3) (48.4) (59.8) (79.9) (87.8)
17.3 40 2.0
1/4
5.8
1/3
10.4
3/4
13.5
3/4
18.5
1
22.0
1-1/2
(1.2) (12.2) (7.6) (22.0) (39.4) (51.1) (70.0) (83.3)
26.0 60 — — — — 7.0
3/4
10.0
1
14.5
1-1/2
16.0
1-1/2
(1.8) (18.3) (26.5) (37.9) (54.9) (60.6)
NOTE: Table shows approximate head-flow for new pump, with a neoprene impeller, in U.S. gallons per minute and liters per minute. For a nitrile
impeller, reduce values by 10%. Progressively longer life may be expected as operating pressures and speeds are reduced. Factory application engi-
neering assistance is recommmended for shaded area. High starting torque motors are required. Pump starting torque in dry condition (no fluid in
pump body) is 45.7 inch-pounds and in wet condition (fluid in pump body) is 39.0 inch-pounds.
