JAC S5 User Manual

S5 Workshop Manual Engine
EM-69
assembly
Air intake pipe bolt
subassembly
M8
15 ~ 20 N•m
M10
18 ~ 25 N•m
Water pipe fixing bolt
M6×12
8 ~ 12 N•m
Camshaft signal wheel bolt
M85×0
15 ~ 22 N•m
Fastening bolts( air intake
pipe support)
M10×18
18 ~ 25 N•m
3.Carbon tank solenoid valve
bolt
M8×10
8 ~ 10 N•m
Fastening bolts( air intake
manifold pipe assembly)
M6×12
8 ~ 10 N•m
Throttle fastening bolt
components
M8×32
5 ~ 10 N•m
Throttle mounting nuts
M8
15 ~ 22 N•m
Fastening bolt components of
oil pressure guide rail
M8×26
10 ~ 13 N•m
Oil pan drain bolt
M14×17
35 ~ 45 N•m
Oil pan bolt 
M6×60
10 ~ 12 N•m
Oil pan bolt 
M6×32
10 ~ 12 N•m
Oil pan bolt 
M6×20
10 ~ 12 N•m
Oil pan side cover bolt
M6×22
10 ~ 12 N•m
Hexagon flange bolt (oil
pump housing)
M8×22
20 ~ 27 N•m
Oil pump housing bolt
M8×32
20 ~ 27 N•m
Air filter support bolt I
M8×45
20 ~ 27 N•m
Air filter support bolt 
M8×38
20 ~ 27 N•m
Air filter support bolt 
M6×20
8 ~ 10 N•m
Oil pump cover bolt
M8×20
15 ~ 18 N•m
Oil pump housing screw plug
M20×1.5
20 ~ 27 N•m
Shaft-end nut
M10
50 ~ 60 N•m
Oil strainer bolt subassembly
M8×20
15 ~ 22 N•m
Screw plug (air filter support)
M18×20
39 ~ 49 N•m
Installing bolt of ignition coil
M6×20
8 ~ 12 N•m
Thermal baffle fastening bolt
M8×12
12 ~ 15 N•m
Catalytic converter fastening
bolt
M8×25
30 ~ 40 N•m
Air exhaust nut
M8
25~30 N•m
M10
30~40 N•m
Timing gear chamber cover
bolt components
M6×25
8 ~ 10 N•m
Timing gear chamber cover
bolt components
M6×28
10 ~ 12 N•m
Composite support nut
M10×20
55 ~ 65 N•m
Composite support nut
M10×1.25-6 H
55 ~ 65 N•m
Idle bolt subassembly
M10×22
30 ~ 42 N•m
Second class tensioner bolt
subassembly
M8×45
15 ~ 22 N•m
Tensioning wheel lever bolt
components
M8×16
23 ~ 27 N•m
Auto-tensioner bolt
M8×51
20 ~ 27 N•m
Coolant temperature sensor
M17
20 ~ 40 N•m
Oil Pressure Switch
R1/8
15 ~ 22 N•m
Crankshaft position sensor
bolt
M6
6 ~ 10 N•m
Knock sensor bolt
M8×28
16 ~ 24 N•m
