S5 Workshop Manual Engine
EM-70
Oxygen sensor
M18
40 ~ 50 N•m
Spark plug
M14×1.25
20 ~ 30 N•m
Thermostat valve seat long
bolt
M8×20
19 ~ 28 N•m
Thermostat valve seat short
bolt
M8×20
19 ~ 28 N•m
Hexagon flange with teeth
nut(thermostat valve seat)
M8
19 ~ 28 N•m
Hexagon flange bolt (water
pump)
M8
23 ~ 27 N•m
Water pump bolt II
M8
23 ~ 27 N•m
Water pump bolt 
M8
23 ~ 27 N•m
Water pump bolt 
M8
23 ~ 27 N•m
Generator support bolt
M8×90
8 ~ 12 N•m
M8×40
20 ~ 25 N•m
Fan bolt
M6
8 ~ 10 N•m
Long bolt of power steering
pump
M8×88
22 ~ 25 N•m
Short bolt of power steering
pump
M8×30
17 ~ 26 N•m
Generator support bolt
M8
20 ~ 25 N•m
Outlet pipe installing bolt
M8×20
10 ~ 15 N•m
Inlet pipe installing bolt
M8×20
10 ~ 15 N•m
Start motor bolt
M10
27 ~ 35 N•m
Water pump pulley bolt
M6×11.5
8 ~ 10 N•m
Low torque bolt
Hexagon flange bolt (cylinder
cover shield cover plate)
M6×22
4 ~ 5 N•m
Air filter
12 ~ 16 N•m
Supercharger connecting
studs
M12×1.5
40 ~ 50 N•m
Supercharger connecting nut
M12×1.5
40 ~ 50 N•m
Supercharger oil return steel
pipe steel pipe bolt
M6
10 ~ 12 N•m
Supercharger support bolt
M10
25 ~ 30 N•m
