3
/
8
2.2The description of each key function
number picture diagram Function description
1
Enter the parameter
area function key
Parameter function entry key
2
Parameter view save
key
View and save the selected parameter number
3 Speed plus Initial standby speed plus
4 Speed reduction Initial standby speed reduction
5
Left key
1
、
adding
2
、
adding
6 Right shift key
1
、
reducing
2
、
reducing
7 Display cutover key
Toggles the window display and needle setting
for the ABCD segment or EFGH segment
8 Front safety switch
Reinforcement sewing part(A-B)
one time or two times Before switching
9 Back safety switch
Reinforcement sewing part(C-D)
one time or two times Before switching
10
W stitch / multi-section
stitch
Short press to select W sewing mode /
long press to select multi-segment sewing mode
11
Restore factory settings
key
Press and hold 3S to restore the factory settings
12
Free stitch/ cut thread
Short press to select free stitch mode /
long press to turn on the thread trimming
function or off it
13
Stop needle position
selection/clip thread
Switch on/off the tension post function when
pressing the top/down needle position shortly
3 Parameters adjustments
3.1 Method to enter into operators parameters and saving
Press for a long time and then press shortly then enters into parameters。Press or to
modify related parameters。If not modified, press to back；if modified successfully, press then
shows ok and back to the main menu. Press to exit the parameters mode.
3.2 Method to enter into technicians parameters and saving
Press
+ for a long time and power on, same method as operators parameter.
