Jackson RackStar Series User Manual

2
07610-004-33-05-E
4 MIN
[102 mm]
12
[305 mm]
22 1/2
[572 mm]
16
[406 mm]
20
[508 mm]
15
[381 mm]
30
[762 mm]
44
[1118 mm]
64
[1626 mm]
Machine
Drain Line
1 1/2 [38 mm]
MIN, Must NOT
Be Reduced.
Pitch 1/4
[6 mm] per ft.
Must Install
Machine Drain
Line above
3 [76 mm] MIN
Floor Drain
or Sink
1 1/2
[38 mm]
MIN
Air-gap
4
[102 mm]
5
[127 mm]
15 1/8
[384 mm]
8
[202 mm]
6 7/8
[210 mm]
21
[533 mm]
ADJUSTABLE FROM 51 1/2 TO 54
[1308 mm TO 1372 mm]
Primary Electrical Opening
(Provided on both ends of machine.)
Secondary Electrical Opening
(Provided on both ends of machine.)
Single-point (Option): uses only
primary opening to power the
entire machine.
Dual-point (Standard): also uses
secondary opening for a
separate connection to
only the booster.
LEGEND
A - Electrical Connection
B - Main Water Inlet
(1/2" NPT, 110 °F MIN (18 kW Booster),
140 °F MIN (12 kW Booster), or 180 °F MIN
(No Booster or Supplied from Steam Booster))
C - Drain Connection
(1 1/2" NPT)
D - Vent Connections
(Including Dampers)
E - Steam Connection
(3/4" NPT)
- Open Door
- High Hood Option
All dimensions from the floor can be increased
1 3/4” using the machine’s adjustable feet.
Items in red are not supplied with the machine.
Items in blue are for the Steam option.
A
25 1/4
[642 mm]
25
[635 mm]
CLEARANCE
(HIGH HOOD)
34 1/4
[870 mm]
TABLE HEIGHT
8
[202 mm]
73 3/4
[1873 mm]
11 3/4
[297 mm]
4 MIN
[102 mm]
19 3/4
[502 mm]
CLEARANCE
(STANDARD)
62 1/4
[1581 mm]
68 1/2
[1740 mm]
68 1/8
[1730 mm]
A
B
44" LEFT-TO-RIGHT
SPECIFICATIONS
44" ELECTRIC/STEAM DIMENSIONS
