21
FR
ACCESSOIRES NÉCESSAIRES POUR LA FIXATION ET LE
RACCORDEMENT DE LA CUVETTE DE WC
COTES D’INSTALLATION
OUTILS POUR L’INSTALLATION
Manchon droit
d’évacuation
+

Tube
d’alimentation
en eau
+

Goujons de

manchons de
protection)
Éponge en
silicone
Unité : mm
180
35
100
135
212
50
lubrifiant
