7
EN
REQUIRED ACCESSORIES FOR IN-WALL CARRIER
INSTALLATION DIMENSIONS
INSTALLATION TOOLS
Extended Drain Pipe
+
Gasket
Flush Pipe
+
Gasket
Bolts
(with protective
sleeve)
Silicone
Sponge
Unit: mm
180
35
100
135
212
50
