35
SP
ACCESORIOS NECESARIOS PARA EL SOPORTE DE PARED
DIMENSIONES DE INSTALACIÓN
HERRAMIENTAS DE INSTALACIÓN
Tubo de drenaje
extendido
+

Tubo de
descarga
+

Pernos
(con funda
protectora)
Esponja
de silicona
Unidad: mm
180
35
100
135
212
50
lubricante
