Jacobsen 67978 – LF 550 User Manual

CONTROLS 3
en-9
!
4131663
A
E
B
F
J
C
G
D
H
K
L
M
N
P
R
W
S
T
U
V
R
A LCD Display Unit (LDU)
B Mow Switch
C Parking Brake Switch
D
Cruise Control Switch
E Ignition Switch
F Horn Switch
G
Light Switch
H Joystick
J Fuel Cap
K Air Cleaner Indicator
L Backlap Switch
M Steering Tilt Lever
N Traction Pedal - Forward
P Traction Pedal - Reverse
R Seat Adjustment
S Hydraulic Oil Cap
T Controller/Fuses
U Engine Throttle Lever
V LDU Push Button
W Access Panel Latch
