3 CONTROLS
en-8
3 CONTROLS
3.1 ICONS___________________________________________________________________
WARNING
Never attempt to drive the mower unless you have read the Safety and Operation Manual
and know how to operate all controls correctly.
Familiarize yourself with the icons shown above and what they represent. Learn the
location and purpose of all the controls and gauges before operating this mower.
Read Manual
High Low
Engine Throttle
Mower Rotation
2-WD 4-WD
Lock Unlock
Forward Reverse
Drive
Travel
Cruise Control
Off Run
Engine
Start
Parking Brake
Forward
(Cut)
Reverse
(Backlap)
Coolant
Temperature
Fuel
Mowers
Lower Raise
Work Lights
Hour Meter
Oil Level Switch
On Off/Test
Engine Oil
Pressure
Glow
Plug
Hydraulic
Oil Filter
Battery
Charge
Warning Lights
Hydraulic Oil
Level
D
!
