2.2 CONTROLS ______________________________________________________________
TC-O/I
77
93
110
° C
170
200
230
° F
Total Hours
1
10
0 0 0 0 0
A
E
M
Q
U
Y
B
1
B
2
F
J
N
S
V
C
G
K
O
R
W
D
H
L
P
T
X
A Tilt Steering Lever
B1 Parking Brake Lock
B2 Parking Brake Release
C Parking Brake
D
Mow Speed Stop
E Traction Pedal - Forward
F Traction Pedal - Reverse
G
Seat Adjustment
H Hydraulic Oil Cap/Dipstick
J Air Cleaner Indicator
K Fuel Cap
L Alarm
M Controller / Fuses
N Hyd. Oil Level Light
O Hyd. Oil Level Switch
P Mower Lift Lever
Q PTO Switch
R Light Switch
S Traction Control
T Engine Throttle
U Ignition Switch
V Hour Meter
W Fuel Gauge
X Warning Lights
Y Engine Coolant Temperature
