Jacobsen AR Series

CONTROLS 4
en-15
4Controls
4.1 OPERATOR COMPARTMENT ________________________________________________
4.2
4.3
4.4
4.5
4.6
4.7
4.2 - Control Panel
4.3 - Armrest Adjuster
4.4 - Traction Pedal
4.5 - Steering Tilt Lever
4.6 - Tow Valve (Under Seat)
4.7 - Brake Valve (Under Floorboard)
