SPECIFICATIONS 11
en-97
11.2 DIMENSIONS & WEIGHTS___________________________________________________
A Width Of Cut 89.0 in. 226.1 cm
B Overall Width 95.3 in. 242.2 cm
C Maximum Width Transport With Cutting Implements Raised 88.6 in. 225.0 cm
D Maximum Height With ROPS in Vertical Position 91.6 in. 232.6 cm
E Height With ROPS Folded 71.5 181.5 cm
F Total Length 137.5 in. 349.2 cm
G Wheel Base 63 in. 160 cm
H Wheel Track Front 74 in. 188 cm
J Wheel Track Rear 55.5 in. 141 cm
Ground Clearance 6.09 in. 15.48 cm
Turning Circle, Curb to Curb (outside tire to outside tire) in Transport
(Left/Right Turn)
262 in. 665 cm
Weight of AR530, Hydraulic and fuel tanks filled, implements lifted 3746lb 1699kg
Weight of AR530, Hydraulic tank full, fuel tank empty, implements lifted 3661lb 1661kg
