4.7 CUTTING UNIT SPECIFICATION
General: Three 686mm (27in) rotary mulching/rear discharge decks.
Drive: Fixed displacement hydraulic motors directly coupled to cutting unit.
Control: Cutting unit lift lever with automatic shut off and safety interlock restart.
Construction:
Heavy duty, welded pressed steel.
Cutting Blades:
Rear Discharge
Low Lift Blade
Height of cut:
Adjustable in 6 mm (0.25 in) increments
19 mm(0.75 in) to 90mm (3.5 in)
Rear roller:
Series EK 76mm (3in) diameter smooth roller.
Series FZ 90mm (3.5in) diameter smooth roller
4.8 CUTTING PERFORMANCE (AREA)
1.0 hectares/hr. at 9.5 km/hr. ( 2.6 acres/hr at 5.9 mph)
10% allowance is included for normal overlaps and turning at the end of each cut.
4 SPECIFICATION
