Jacobsen G-Plex III Parts And Maintenance Manual

Parts-91
* Not Illustrated
LIST OF PARTS
ITEM RANSOMES DESCRIPTION QTY REMARKS
PART NO
JACOBSEN G PLEX III Series: DN & DP
MAINTENANCE AND PARTS MANUAL
44 TURF GROOMER ROLLER ASSENBLY
1 390899 Tube, roller, 1/4" spacing 1 Product No. 067871
1 390900 Tube, roller, 1/2" spacing 1 Product No. 067873
2 365330 Bearing, ball 2
3 338772 Shaft, roller 2
4 338773 Seal, grease 2
5 458113 Snap ring 2
6 446148 Lockwasher, 7/16" 2
7 443186 Nut, 7/16-20, jam 2
8 452008 Washer, 7/16" 2
9 443836 Nut, 7/8-14, jam 4
10 365345 Ring, nylos 2
11 471214 Fitting, grease, 1/4-28 2
