Jacobsen G-Plex III Parts And Maintenance Manual

GB-31
JACOBSEN G-PLEX III Series: DN & DP
MAINTENANCE AND PARTS MANUAL
GB
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
UBlue
N Brown
BG Black Green
BO Black Orange
NU Brown Blue
WG White Green
WY White Yellow
7 SCHEMATICS
1 Starter Motor
2 Battery +ve Terminal
17 Backlap Switch
25 Alternator
27 Starter Solenoid Batt +ve Terminal
28 Starter Solenoid
29 Engine Kill
30 Oil Pressure Sender
32 Carburetor Solenoid
35 Solenoid Ground
36 Headlight
37 Headlight
38 Raise Solenoid
39 Lower Solenoid
40 Reel Solenoid
41 Seat Switch
56 Instrument Connector 1
57 Instrument Connector 2
58 Instrument Connector 3
59 Paddle Switch
60 Foot Switch
62 Parking Brake / Neutral Switch
