9 MAINTENANCE
en-47
9.2.6 SWITCH STATUS__________________________________________________________
Shows the current switch settings to identify a possible problem with the switch. A status of 0
indicates the switch is in the OFF position. A status of 1 indicates the switch is in the ON
position. Check the wires and operation of any switch that does not show the correct status.
The Switch status is displayed two screens LDU BYTE 1 and LDU BYTE2. To toggle between the screens press the
LDU button. Each screen displays 8 numbers, these correspond to the following switches:
9.2.7 MAINTENANCE INTERVAL RESET ___________________________________________
The Maintenance Timer Reset will prevent the MAINTENACE INTERVAL screen to be shown on the LDU until the next
maintenance interval is reached. The maintenance interval is set for each 50 hour interval (50, 100, 150 etc).
To reset the maintenance interval, press forward or backward on the joystick until the MAINT
FLAG RESET screen is shown on the LDU. Press the LDU button to reset the maintenance
interval.
9.2.8 BACKLAP REQUEST ______________________________________________________
The backlap request screens are used to backlap the reels. See Section 9.19 for the
backlap procedure.
SWITCH STATUS
0100 0100
SWITCH STATUS
LDU#1 BYTE #1
0 1 0 0 0 1 0 0
Lights Joystick Up Joystick Down Cruise Control Mow SW ParkBrake Start SW Spare Horn LDU Pushbutton RH Wing Enable Lh Wing Enable Reserved Regen Inhibt Regen Request Spare
SWITCH STATUS
LDU#1 BYTE #2
0 1 0 0 0 1 0 0
MAINT FLAG RESET
YES
BACKLAP
ENABLE?
LOWER ALL
ACTUATORS
10 MINUTES
< START >
ACTUATE PTO
SWITCH
10 MINUTES
< QUIT >
