101
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
4132078 1 Charge Pump Kit
2 4120216 1 • Carrier
3 N/S 6 • Roller
4 N/S 4 • Screw, 5/16-18 x 1-1/4” Hex Socket
5 N/S 1 • Screw, 5/16-18 x 1-3/4” Hex Socket
6 4120217 1 • Pin, Drive
● 7 549354 1 • Seal, Square Cut Ring
● 8 549380 1 • Seal, Square Cut Ring
9 549609 1 • Plate, Pump
10 546437 2 • Snap Ring
11 N/S 1 Retaining Ring
12 4195121 1 Bearing, Ball
● 13 546415 2 Oil Seal
14 N/S 1 Cover, Pump
15 4195120 1 Input Shaft
16 502459 1 Pump, Ball Rotor
17 N/S 1 Pump Race
18 N/S 1 Cam Ring
19 N/S 1 Insert, Cam Ring
20 N/S 1 Pintle Assembly
21 N/S 1 • Coil Pin
22 N/S 1 • Dowel
23 N/S 2 • Piston, Dampening
● 24 N/S 2 • Backup Ring
● 25 N/S 2 • O-Ring
26 N/S 1 • Upper Acceleration Valve
27 N/S 1 • Lower Acceleration Valve
28 N/S 2 • Check Valve
29 N/S 1 • Charge Pressure Relief Valve
30 549365 2 Spring, Tow Valve
31 N/S 1 Bracket, Pins
● 32 549376 1 Seal, Square Cut Ring
33 554377 1 Cover, Pintle
34 N/S 4 Screw, 5/16-18 x 1” Hex Socket
35 N/S 2 Screw, 5/16-18 x 1” Torx Socket
36 N/S 1 Control Shaft
37 361631 1 Fitting, -10 ORB Barbed
339899 1 • O-Ring, -10 ORB
38 549379 2 Button
39 N/S 1 Washer, Control Shaft
40 N/S 1 Pin, Dowel
41 N/S 1 Shaft, Tow Valve
42 N/S 1 Nut, Gasket
43 N/S 1 O-Ring
44 N/S 1 Fitting, O-Ring Guide
45 N/S 1 Pin, Dowel
2500620 1 Seal Kit Includes Items marked ●
