TRI-KING
17.1 Fuel Control
Serial No. All
Item Part No. Qty. Description Serial Numbers/Notes
1
2810134 1 Bracket, Throttle Cable
2 361898 1 Screw, M8-1.25 x 16 mm Hex Head
3 446136 1 Lockwasher, 5/16 Heavy
4 400112 4 Screw, 1/4-20 x 1” Hex Head
5 3004410 1 Spacer
6 1004340 1 Cable, Throttle See 4.1 For Handle Mounting
7 446130 7 Lockwasher, 1/4 Heavy
8 443102 5 Nut, 1/4-20 Hex
9 400108 1 Screw, 1/4-20 x 7/8” Hex Head
10 444708 1 Locknut, 1/4-20 Hex Center
11 2810088 1 Bracket, Solenoid
12 362535 2 Screw, M6-1 x 16 mm Hex Head
13 453023 2 Flat Washer, 1/4
14 338289 1 Solenoid, Fuel Shutoff REFERENCE K1, See 42.1
15 443104 1 Nut, 1/4-28 Hex
16 2810546 1 Rod, Solenoid
