6 MAINTENANCE & LUBRICATION CHARTS
30
6.3 MAINTENANCE CHARTS ___________________________________________________
A - Add or Adjust C - Clean I - Inspect L- Lubricate R - Replace AR - As Required
* Indicates initial service for new machines.
** Every 250 hours, or yearly whichever comes first.
*** Inspect visible hoses and tubes for leaks or oil marks.
I - Manual grease gun with NLGI Grade 2 (Service Class LB).
II - Engine Oil - See Section
4.3.
III - Use Jacobsen GreensCare 68 Biodegradable fluid: Capacity: 5 gallons (19 Liters). Order Part No. 5003103 containing 5 gal.
(19 l), pail or Part No. 5003102, 55 gal. (208 l) Drum.
IV - Capacity: 3qt. (2.8 l) 50/50 water ethylene glycol mix.
Recommended Service and Lubrication Intervals
Every
8-10
Hours
Every
50
Hours
Every
100
Hours
Every
250
Hours
Every
400
Hours
Every
500
Hours
Every
1000
Hours
Yearly See
Section
Lubricant
Type
Air Filter
IAR R4.4
Battery Charge
I4.7
Belts
I-A* I-A R 3.2,
3.3
Brake
I-A* A 3.10
Cooling System
I-C-A R 4.18 IV
Electrical System
I* I 4.13
Engine Oil
IR*R 4.3 II
Engine Oil Filter
R* R
Fuel System
I4.6
Fuel Filter
R4.6
Grease Fittings - All
LLL L 6.2 I
Hydraulic Hoses and Tubes
I*** I 4.10
Hydraulic Oil
I-A R** R** 4.11 III
Hydraulic Oil Filter
I R* R 4.12
Muffler and Exhaust
I I 4.14
Radiator Screens
I-C/AR 4.18
Tires
I-A 4.15
