35
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
2810064 1 Pivot Bracket
2 2811139 AR Shim, Hood
3 441676 2 Carriage Bolt, 3/8-16 x 1-1/4”
4 453011 2 Flat Washer, 3/8
5 446142 6 Lockwasher, 3/8 Heavy
6 443110 6 Nut, 3/8-16 Hex
7 2811495 2 Pivot Link
8 400408 4 Screw, 1/2-13 x 1-1/2” Hex Head
9 452012 8 Flat Washer, 1/2
10 3000576 4 Washer, Nylon
11 443818 8 Nut, 1/2-13 Hex Jam
12 4201302 1 Hood, Left Side
13 400188 3 Screw, 5/16-18 x 1” Hex Head
14 3004410 3 Spacer
15 446136 3 Lockwasher, 5/16 Heavy
16 443106 3 Nut, 5/16-18 Hex
17 3002673 2 Bracket, Hood Stop
18 400260 4 Screw, 3/8-16 x 7/8” Hex Head
19 354989 2 Stop, 3/8-24 Rubber
20 443812 4 Nut, 3/8-24 Hex Jam
21 2810029 1 Hood, RIght Side
22 1001758 1 Rubber Latch and Keeper
23 403912 3 Screw, #10-24 x 5/8” Truss Head
24 4199660 1 Bracket, Upper Radiator See 13.1
25 2810413 1 Right Foot Rest See 3.1
To Next Page
