37
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
5001665 1 Seat Pan Includes Decals
2 3003301 1 Seat Base
3 440134 2 Carriage Bolt, 3/8-16 x 3”
4 446142 2 Lockwasher, 3/8 Heavy
5 443110 2 Nut, 3/8-16 Hex
6 400188 4 Screw, 5/16-18 x 1” Hex Head
7 452006 12 Flat Washer, 5/16
8 445795 18 Nut, 5/16-18 Spiralock Flange
9 403770 14 Screw, 5/16-18 x 3/4” Hex Flange
10 3002803 1 Left Side Transition
11 3002804 1 Right Side Transition
12 2810411 1 Left Foot Rest
13 2810413 1 Right Foot Rest
14 400260 12 Screw, 3/8-16 x 7/8” Hex Head
15 452008 12 Flat Washer, 3/8
16 445796 12 Nut, 3/8-16 Spiralock Flange
17 3003299 1 Hinge, Seat Plate
18 440078 5 Carriage Bolt, 5/16-18 x 3/4”
19 551651 1 Moulding 10 Foot Length, Cut to 7 in.
20 446136 10 Lockwasher, 5/16 Heavy
21 443106 10 Nut, 5/16-18 Hex
22 3004410 3 Spacer
23 3003402 1 Seat Latch
24 443806 2 Nut, 5/16-18 Hex Jam
25 3003368 1 Plate, Seat
26 558012 2 Pad, Cork 10 Foot Length, Cut to 8 in.
27 303567 1 Grommet
28 440088 1 Carriage Bolt, 5/16-18 x 1-3/4”
29 3003968 1 Cover, Filter
30 4139430 1 Seat
31 523356 1 • Seat, Adjuster with Handle
32 523357 1 • Seat Adjuster
33 4139450 1 • Seat Switch REFERENCE SW6, See 42.1
34 3001328 6 • Screw, 5/16-18 x 5/8” Washer Head
35 5003769 1 Harness, Seat Switch
36 2810062 1 Pad, Left Foot Rest
37 2810061 1 Pad, Right Foot Rest
38 3003928 1 Literature Pouch
39 844945 AR Trim, Seal 30 Ft. Length, Cut to 11”
40 3001328 2 Screw, 5/16-18 x 5/8” Washer Head
