41
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
2811437 1 Instrument Panel
2 3003350 1 • Decal, Panel Overlay
3 2811597 1 • Decal, Parking Brake
4 3002053 1 • Decal, Backlap Switch
5 1001958 1 Ignition Switch REFERENCE SW9, See 42.1
6 5002101 1 • Bezel, Slotted Rubber
7 5002102 1 • Nut, 5/8-32 Black Nylon
8 5000039 2 • Key, Ignition Switch
9 1001010 1 Switch, Backlap Lockout REFERENCE SW10, See 42.1
10 558036 2 • Nut, 13/16-20 Hex Panel
11 N/S 1 • Lockwasher, 13/16 Internal Tooth
12 5001428 1 • Key, Backlap Lockout Switch
13 3001780 1 Switch, Reel / 3WD REFERENCE SW2, See 42.1
14 N/S 1 • Nut, 15/32-32 Hex Panel
15 447220 2 • Lockwasher, 1/2 Internal Tooth
16 162723 1 Gauge Hour Meter REFERENCE U3, See 42.1
17 N/S 1 • Bracket, Gauge
18 447006 1 • Lockwasher, #10 External Tooth
19 444310 1 • Nut, #10-24 Hex Nut
20 162721 1 Gauge, Volt Meter REFERENCE U2, See 42.1
21 N/S 1 • Bracket, Gauge
22 444306 2 • Nut, #8-32 Hex
23 447206 2 • Lockwasher, #8 External Tooth
24 447002 2 • Lockwasher, #6 Internal Tooth
25 444304 2 • Nut, #6-32
26 444306 4 Nut, #8-32 Hex
27 162720 1 Gauge, Water Temperature REFERENCE U4, See 42.1
28 N/S 1 • Bracket, Gauge
29 444306 2 • Nut, #8-32 Hex
30 447206 2 • Lockwasher, #8 External Tooth
31 447002 3 • Lockwasher, #6 Internal Tooth
32 444304 3 • Nut, #6-32
33 338601 1 Circuit Breaker, 10 Amp REFERENCE CB2, See 42.1
34 364774 1 Boot, 15/32-32 Circuit Breaker
35 363961 1 Switch, Glow Plug Toggle REFERENCE SW1, See 42.1
36 N/S 2 • Nut, 15/32-32 Hex Panel
37 363962 1 Boot, 15/32-32 Toggle Switch
38 366751 1 Light, Parking Brake REFERENCE L4, See 42.1
39 164194 1 Light, Oil Pressure REFERENCE L3, See 42.1
