43
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
2811387 1 Traction Pedal
2 328133 2 Bushing Included with frame
3 453017 6 Flat Washer, 1/2
4 460028 1 Cotter Pin, 1/8 x 1”
5 2811390 1 Spring, Torsion
6 2811654 1 Arm, Switch Actuating
7 352936 1 • Bushing
8 3003475 1 Pedal, Grip
9 400190 1 Screw, 5/16-18 x 1-1/4” Hex Head
10 453009 2 Flat Washer, 5/16
11 446136 1 Lockwasher, 5/16 Heavy
12 443806 1 Nut, 5/16-18 Hex Jam
13 400118 1 Screw, 1/4-20 x 1-3/4” Hex Head
14 2811659 2 Spacer, Nylon
15 2812215 1 Plate, Switch Mounting See 8.1 for plate mount.
16 444708 2 Locknut, 1/4-20 Hex Center
17 403860 4 Screw, #8-32 x 5/8” Truss Head
18 3007392-1 1 Switch, Neutral Proximity REFERENCE SW7, See 42.1
19 4140149 1 Switch, 3WD Proximity REFERENCE SW5, See 42.1
20 3009193 AR Shim, Proximity Switch
21 453004 4 Flat Washer, #8
22 446110 4 Lockwasher, #8
23 444306 4 Nut, #8-32 Hex
24 3002399 1 Rod, Traction Linkage
25 443108 2 Nut, 5/16-24 Hex
26 343398 2 Ball Joint
27 444754 2 Locknut, 5/16-24 Hex Center
28 452006 4 Flat Washer, 5/16
29 1004900 1 Traction Arm
30 307374 1 Washer
31 454001 2 Spring Washer
32 463005 1 Key, 1/8 x 5/8” Woodruff
33 444758 1 Locknut, 1/2-13 Center
34 3002372 2 Bolt, 3/8-16 Spring
35 443110 4 Nut, 3/8-16 Hex
36 3006746 1 Sping, Extension Reverse Return
37 3006745 1 Spring, Extension Forward Return
38 441606 1 Carriage BOlt, 1/4-20 x 3/4”
39 4129590 1 Pump, Hydraulic Traction See 20.1 for pump mounting.
40 443106 2 Nut, 5/16-18 Hex
41 400192 1 Screw, 5/16-18 x 1-1/2” Hex Head
42 471214 1 Grease Fitting, 1/4-28 Straight
● Frame Components
To Next Page
