49
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
N/S 1 Frame Assembly
2 328133 4 Bushing, Pedal Pivot
3 3002170 4 Bushing, Lift Arm Pivot
4 365106 2 Bushing, Lift Crank
5 471216 1 Grease Fitting, 1/4-28
6 4182425 1
Wheel Motor, 11.9 in
3
Front Left
See 40.1
7 4189920 1
Wheel Motor, 9.6 in
3
Front Right
See 41.1
8 554780 1 Key
9 554779 1 Nut, 1-20 Slotted Hex
10 400410 4 Screw, 1/2-13 x 1-3/4” Hex Head
11 446154 8 Lockwasher, 1/2 Heavy
12 443118 8 Nut, 1/2-13 Hex
13 400414 4 Screw, 1/2-13 x 2-1/4” Hex Head
14 1001634 1 Caliper, Left Side See 39.1
15 1001635 1 Caliper, Right Side See 39.1
16 3008482 2 Spacer
17 395388 2 Hub, Wheel
18 447030 2 Lockwasher, 1” External Tooth
19 4242563 2 Tire, 20 x 10 - 10 Grassmaster
20 4242564 2 Rim, 10 x 7
21 360111 1 Valve, Inflation
22 353914 8 Wheel Bolt, 1/2-20 x 3/4”
23 400188 2 Screw, 5/16-18 x 1” Hex Head
24 452006 2 Flat Washer, 5/16
25 445781 2 Nut, 5/16-18 Whizlock Flange
26 4197061 1 Frame, Steering Column
27 4196485 1 Valve, Steering
4197940 1 Seal Kit
28 64205-054 4 Screw, M8-1.25 x 130 mm Hex Head
29 4211400 4 Spacer
30 4210420 1 Shaft, Steering
31 4201840 1 Seal, Steering Shaft
32 443828 1 Nut, 5/8-18 Hex Jam
33 450168 4 Screw, M6-1 x 12 mm Hex Head
34 450410 4 Lockwasher, M6
35 2811364 1 Steering Wheel
36 2811365 1 Cap, Steering Wheel
37 2811547 5 Washer
38 447224 1 Lockwasher, 5/8 Internal Tooth
39 354080 2 Clamp, Hose
40 446136 1 Lockwasher, 5/16 Heavy
41 443106 1 Nut, 5/16-18 Hex
42 3003748 2 Edging
